Greenlee CS-8000 Circuit Seeker User Manual

CS-8000
13
Typical Applications
Locating Breakers
Tracing Circuits and Conduit
Locating the correct panel
Finding the strongest
signal on the breaker
Tracing live GFCI-protected circuits
Tracing a circuit using a separate ground
to a different branch circuit
Tracing a circuit using a separate ground
to a metallic object
Tracing conduit, data (or other low
voltage cable), or coax
Scanning the breakers
Checking the signal
on the wire
OR
Strong Signal Setup–
No Signal Canceling
Circuit
under
Test
Separate
Circuit
Coax
OR
Low Voltage or Data Cable
Conduit
If possible, ground
far end of conductor
or cable shield.
Connect
to conduit,
a cable
conductor,
or shield
of coax.
