Greenlee CS-8000 Circuit Seeker User Manual

CS-8000
5
Identification
Display Icons
12. Relative Signal Strength
13. Transmitter Signal Indicator
14. Mode (Breaker–Search)
15. Absolute Signal Strength
2
4
3
1
8
9
10
11
7
5
6
SEARCH MODE
Signal Strength
AUTO GAIN
OPEN
SEARCH MODE
Signal Strength
MANUAL GAIN
LIVE
12
13
14
15
16
18
17
16. Gain Mode (Auto–Manual)
17. Signal adjustment arrows
(Manual Gain only)
18. Line Status (Live–Open)
Transmitter
7. Connectors (non-polarized)
8. Power LED
9. Live Line LED
10. Low Battery LED
11. Power pushbutton
Receiver
1. Sensing surface
2. Display
3. Mode Selector
4. Decrease Manual Gain
5. Increase Manual Gain
6. Power/Signal Reset pushbutton
Symbols on the Unit
Warning—Read the instruction manual
Double insulation

Greenlee CS-8000 Circuit Seeker Specifications

General

Brand	Greenlee
Model	CS-8000 Circuit Seeker
Category	Measuring Instruments
Language	English
