Greenlee DM-810A - AC and DC Current Accuracy

22
Accuracy (cont’d)
AC Current (AC + DC Current on DM-830A and DML-430A Only)
Range
Accuracy at
50 to 60 Hz
Accuracy at
40 to 1 kHz
Burden Voltage (typical)
(all frequency ranges)
600.0 µA ± (0.6% + 0.3 µA) ± (0.8% + 0.4 µA)
0.08 mV/µA
6000 µA ± (0.6% + 3 µA) ± (0.8% + 4 µA)
60.00 mA ± (0.6% + 0.03 mA) ± (0.8% + 0.04 mA)
2.1 mV/mA
600.0 mA ± (1.0% + 0.3 mA) ± (1.0% + 0.4 mA)
6.000 A ± (0.8% + 0.006 A) ± (0.8% + 0.006 A)
0.02 V/A
10.00 A ± (0.8% + 0.06 A) ± (0.8% + 0.06 A)
10 A continuous, 20 A for 30 sec. maximum with 5 minute cool down.
DC Current
Range Accuracy at 50 to 60 Hz
Burden Voltage (typical)
(all frequency ranges)
600.0 µA ± (0.2% + 0.4 µA)
0.08 mV/µA
6000 µA ± (0.2% + 4 µA)
60.00 mA ± (0.2% + 0.04 mA)
2.1 mV/mA
600.0 mA ± (0.2% + 0.4 mA)
6.000 A ± (0.2% + 0.004 A
0.02 V/A
10.00 A ± (0.2% + 0.04 A)
10 A continuous, 15 A for 30 sec. maximum (20 A for DML-430A) with 5 minute cool down.
Line Level Frequency
Function Sensitivity (Sine RMS) Range
60.00 mV 40 mV 15.00 Hz to 50.00 kHz
600.0 mV 60 mV 15.00 Hz to 50.00 kHz
9.999 V 2.5 V 15.00 Hz to 10.00 kHz
99.99 V 25 V 15.00 Hz to 10.00 kHz
999.9 V 100 V 15.00 Hz to 10.00 kHz
600.0 µA 45 µA 15.00 Hz to 3.000 kHz
6000 µA 600 µA 15.00 Hz to 3.000 kHz
60.00 mA 40 mA 15.00 Hz to 3.000 kHz
600.0 mA 60 mA 15.00 Hz to 3.000 kHz
6.000 A 4 A 15.00 Hz to 3.000 kHz
10.00 A 6 A 15.00 Hz to 3.000 kHz
