Greenlee G3 - Page 19

G3 Tugger
®
System
Motor Assembly Parts List
1 52066885 Frame weldment assembly ................... 1
2 Guard, chain (bottom) ...........................1
3 Guard, chain (top) .................................1
4 Gearmotor .............................................1
5 Electrical box assembly ........................1
6 Screw unit .............................................1
7 Cap, end ...............................................1
8 Spacer...................................................1
9 52066743 Capstan assembly ................................1
10 Chain, roller, #40, 1/2" pitch .................1
11 Sprocket, driver ....................................1
12 Screw, cap, #10-32 x 3/8 ......................1
13 Washer, at, #10 x 5/8 OD .................... 1
14 Sprocket ...............................................1
15 Screw, cap, sbh, 1/4-20 x 1.00 ............. 4
16 Washer, thrust ....................................... 2
Key Part No. Description Qty Key Part No. Description Qty
17 Washer, at, 1.00 x 1.50 x .031 ber ....1
18 Screw, cap, 1/4-20 x .625 hex hd ......... 4
19 Screw, cap, 1/4-20 x .500 skt hd .......... 1
20 Ring, retaining, .500 Truarc #5100 EX...1
21 Pawl ......................................................1
22 Spring, torsion ......................................1
23 Screw, slftpg-phll hd, #10-16 x .250 .....6
24 Washer, shim,
ø .5 ID x ø .75 OD x .031 ......................2
25 Nut, hex, 1/4-20 ....................................1
52066182 Motor guard assembly kit
(includes 2, 3, 23)
52066181 Motor assembly kit (includes 4, 5)
52066179 Capstan unit assembly kit
(includes 6–9, 16, 17)
52066180 Sprocket unit assembly kit
(includes 10–15)
52066183 Pawl assembly kit (includes 19–22, 25)
52054433 Armature and eld
52054434 Brush and cap
ILLUSTRATIONS AND PARTS LISTS (cont’d)
