GreenWorks 25223 User Manual

32
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 31104488 Upper handle assy. 1
1.1 33310470-2 Upper handle 1
1.2 34135486 Foam grip 1
2 33305469-3 Bail switch 1
3 31107486 Cable box assy. 1
3.1 34136486 Start button 1
3.2 33401229 Spring 1
3.3 34122486 Cable box cover (upper) 1
3.4 34123469 Compressor 1
3.5 3220735 Screw ST3X8-C 3
3.6 31901250 Start cable (short) 1
3.7 33318250 Compressed spring 1
3.8 34118250 Block 1
3.9 32204250 Bolt 1
3.10 33317250 Slide block 1
3.11 33316250 Torsion spring 1
3.12 33315250 Spring 1
3.13 32201305 Nut M3 1
3.14 31902469 Start cable (long) 1
3.15 34121486 Cable box cover (lower) 1
3.16 32201572 Screw 4
4 3220439 Lock nut M5 12
5 33323250-1 Bail stop 1
6 33302463-4 Lower handle 1
7 34103466-3 Cam lock block 2
8 34106467-1 Handle knob M8 4
9 31103487 Cam lock assy. 2
9.1 32901466 Dowel pin 5×26 2
9.2 34102466-3 Cam lock lever 2
9.3 33201466 Cam lock bolt 2
10 34135469A Cable clamp 1
11 3220435 Screw M5×15 6
12 33905470 Spring 1
13 33904470 Spring 1
14 33203470 Axle 1
15 34105488 40V handle 1
16 34103488 Battery door 1
17 34102488 Battery housing 1
18 34106976 Insert block 1
19 34104488 40V battery holder 1

GreenWorks 25223 Specifications

General

Brand	GreenWorks
Model	25223
Category	Lawn Mower
Language	English
