11 3220951D 5 Screw
12 333013431A 1 Deck
13 32202390A 4 Bolt
14 32204113D 4 Screw
15 311021179 1 Front wheel axle
16 33307470 4 Axle press plate
17 32204113D 8 Screw
18 341281179A 2 8” Wheel assembly
19 341021179B 1 Front panel
20 3220343 2 Nut
21 332081531 1 Height adjustment link bar
22 32243563 4 Nut
23 332011179 1 Height adjustment tension spring
24 341033431 1 Rear baffle
25 3220951D 7 Screw
26 333041519D 1 Height adjustment bracket (left)
27 3221637 4 Bolt
28 341251179A 1 Rear cover
29 32910131 4 Nut
30 312011560 2 Mechanical vertical switch assembly
31 342031179 2 Rubber plug
32 333031577 1 Height adjustment bracket (right)
33 3290506 2 Clip washer
34 332021179 1 Rear cover axle
35 332111179 1 Torsinal spring (rear cover)
36 33401222 1 Torsinal spring
37 339031546 1 Cotter pin
38 311083431 1 Rear wheel axle
39 342011179 1 Rear shield
40 3220505D 4 Screw
41 332041179 1 Press board
42 341602376 2 10” Wheel assembly
43 332061179 2 Pin
44 341151546 2 Knob
45 332051179 2 Spring
46 332071179C 2 Limit column
47 332081179C 2 Block
48 311063459 1 Height adjustment bar assembly
49 32201467 2 Nut
14
