GreenWorks 48SPM21 - Exploded View

13 EXPLODED VIEW
No. Part No. Qty Description
1 311013460 1 Motor assembly
2 333021527 1 Pad
3 341191179-1 1 Fan
4 341241179C 1 Side discharge chute
5 341331179U 1 Bumper cover
6 32205836 4 Screw
7 341061179C 1 Bumper main body
8 311201546 1 Side discharge cover assembly
9 333041179 1 Blade
10 322011179AC 1 Bolt
13
