1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.
1.2 OVERVIEW
Figure 1 - 20.
1
Trigger
2
Lock-out button
3
Upper shaft
4
Auxiliary handle
5
Lower shaft
6
Guard
7
Cut-off blade
8
Trimmer head
9
Guard cap
10
Blade
11
Release button
12
Positioning hole
13
Hex wrench
14
Central knob
15
Cap
16
Lower support
17
Spool cover
18
Spool
19
Tab
20
Line exist hole
21
Wrench
22
Nut
23
Outer cup
24
Outer ring-nut
25
Inner cup
26
Angle transmission hole
27
Bump knob
A
Direction of roatation
B
Best cutting area
C
Dangerous cutting area
2 SAFETY
WARNING
Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Remove the battery pack from the machine before
installation.
WARNING
Do not use accessories that are not recommended for this
machine.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine before
use.
WARNING
• If the parts are damaged, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the service
center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with local
regulations.
3.2 ATTACH THE GUARD
Figure 2.
WARNING
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a Phillips
screwdriver (not provided).
2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw holes
on the trimmer head.
4. Tighten the screws.
5. Put the guard cap onto the guard.
6. Align the screw holes on the guard cap with the screw
holes on the guard.
7. Tighten the screws.
3.3 ASSEMBLE THE SHAFT
Figure 3.
1. Loosen the screw on the coupler.
2. Push in the release button on the lower shaft.
