1 DESCRIPTION
1.1 PURPOSE
This machine is used for domestic lawn mowing. The
cutting blade must be approximately parallel to the
ground. All four wheels must touch the ground while you
mow.
1.2 OVERVIEW
Figure 1-11.
1
Handle knob
2
Lower handle
3
Bracket
4
Upper handle
5
Bolt
6
Knob
7
Grass catcher
8
Mulch plug
9
Side discharge chute
10
Rear discharge door
11
Grass catcher handle
12
Hook
13
Door rod
14
Mulch plug handle
15
Discharge chute
16
Side discharge door
17
Recesses
18
Pivot
19
Height adjustment lever
20
Battery door
21
Battery compartment
22
Safety key
23
Battery release button
24
Start button
25
Handle bar
26
Bail switch
27
Self-propel lever
28
Speed control button
29
Blade
30
Wood
31
Mounting screw
32
Arrows
2 SAFETY
WARNING
Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Do not change or make accessories that are not
recommended by the manufacturer.
WARNING
Do not put in the safety key or the battery pack until
you assemble all the parts.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts are damaged, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
3.2 UNFOLD THE LOWER HANDLE
Figure 2.
1. Pull and turn the handle knobs 90°.
2. Unfold the lower handle.
3. Line up the handle knobs in one of the three
positions on the brackets.
4. Turn the handle knobs 90° until they engage the
holes in the brackets.
NOTE
Make sure that the two handle knobs are in the same
position.
WARNING
Do not make damage to the cables when you fold or
unfold the handle.
3.3 INSTALL THE UPPER HANDLE
Figure 3.
4
