No. Part No. Description Qty.
20 33302222-1 Height adjustment bracket (left) 1
21 32201235D Screw M6x8 4
22 3320238A Spindle bushing 1
23 32208261 Nut 4
24 3410237A Fan 1
25 3420436 Spring cover 3
26 33304235 Rear cover spring (left) 1
27 34104236 Mulching plug 1
28 34106236 Rear baffle 1
29 34103236-5 Rear cover 1
30 33302235 Rear cover spring (right) 1
31 34135486 Sponge tube 1
32 32204113D Screw 4
33 31102489B Switch box assembly 1
34 31102467D Quick release fastener 2
35 333022325 Upper handle 1
36 33305469D Power lever 1
37 341081165 Cord retainer 2
38 32205590 Screw 2
39 341062325 Isolation sleeve 2
40 333032325 Lower handle 1
41 34106467-1 Handle knob 4
42 3410438-3 Side discharge chute 1
43 3220246D Screw 2
44 3411435 Line pressing board 1
45 341031576A Right main house 1
46 36101489 Motor 1
47 341042325 Left main house 1
48 322081163 Screw 4
49 341071576 Decorative cover 1
50 32207110D Screw 10
51 341022325 Upper cover 1
52 3221237 Self-lock nut M4 2
53 333061161-1 Cord Clip 2
54 322061163 Screw 2
55 3320138-1 Rear cover rod 1
56 34127229 Rear shield 1
57 3290506 Clip washer 1
15
