13
OPERATION
This Lithium-ion battery pack is equipped with an internal circuit breaker which will automatically
shut off the power to the tool and then reset itself once cooled.
Follow these steps if an overload occurs while under heavy use:
1. Release the power switch and restart tool by depressing switch.
2. The battery may need to be removed for approximately 1 minute, allowed to cool and then
reinstalled for use.
IMPORTANT
STARTING AND STOPPING (See Figure 7)
TO START THE MOTOR:
• Fit the battery pack into the polesaw.
• Pull the small safety lock button upward using your thumb.
• Squeeze the safety lock button.
• Squeeze the trigger.
TO STOP THE MOTOR:
• Release the trigger.
Fig. 7
Small safety lock button
Trigger
Safety lock button
