18
OPERATION
3. Wind the lines clockwise around the spool simultaneously, as shown by the arrows on the
spool.
4. Place the line in the slot on the spool ange, leaving about 6 in. ( 152 mm ) extended
beyond the slot.
NOTE: Do not overll. After winding the line, there should be at least 1/4 in. (6mm) between the
wound line and the outside edge of the spool.
5. Place the spool in the trimmer head as shown below.
6. Insert the end of the line through the line exit hole in the side of the cover.
Line exit hole
Fig. 9.3
Fig. 9.4
Fig. 9.6
Spool Flange
Fig. 9.5
