1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.
1.2 OVERVIEW
Figure 1 - 12.
1
Trigger
2
Lock-out button
3
Rear handle
4
Auxiliary handle
5
Upper shaft
6
Coupler
7
Lower shaft
8
Cut-off blade
9
Edge guide
10
Trimmer head
11
Guard
12
Screw
13
Knob
14
Release button
15
Positioning hole
16
Metal ring
17
Knob
18
Battery release button
19
Spool retainer button
20
Spool cover
21
Spool
22
Tab
23
Hole
24
Spool housing
25
Anchor hole
26
Slot
A
Direction of roatation
B
Best cutting area
C
Dangerous cutting area
2 INTRODUCTION
Your product has been engineered and manufactured to high
standards for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of
rugged, trouble-free performance.
3 GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your battery-
operated (cordless) power tool.
3.1 TRAINING
• Read the instructions carefully.
Be familiar with the controls
and the correct use of the
machine.
• Never allow children, persons
with reduced physical, sensory
or mental capabilities or lack
of experience and knowledge
or people unfamiliar with these
instructions to use the
machine. Local regulations can
restrict the age of the operator.
• Keep in mind that the operator
or user is responsible for
accidents or hazards occurring
to other people or their
property.
3.2 PREPARATION
• Before use, check the battery
pack for signs of damage or
aging. If the battery becomes
damaged during use, switch
2
English
EN
