Operation manual SP 9 - Compact
CHAPTER III – DESCRIPTION OF PLOUGH – Page 3
3.3. The SP 9- Compact PLOUGH SPECIFICATION
Parts Standard equipment Optional equipment
Pulling equipment • Articulated Cat. II and III. width Automatic pulling equipment.
Quick -Coupler
Reverse
• Mechanism lifting rack bar
Beam/frame
• Modulated 180 x 180 fastened
staff (7’’x7’’)
, plough heads can be
added
• Other plough heads
Directing during
transportatio
n
• In transporting position the wheel
can be dire
cted accodingly to the
plough inclination.
Working width • In the case of 100 cm plough
distance
it can be variated from
12’’ to 20‘’, in the case of 114 cm it
can be variated from 14’’ to 22’’
The adjusting of the first
furrow (déport)
• Mechanical arm • During operation it can be
adjusted by hydraulic cylinder
Distance between
plough ends (plough
bottom distance)
• 100 cm (= 39’’) • 114 cm (= 45’’)
The height of the end • 170 cm (= 67’’). • 160 cm (= 63’’) • 180 cm (= 71’’)
Staff clearance
• 76 cm (= 30’’)
Securities • Shearing: At the turning the
plough do not hold plough mass
by this the staff damaging can be
avoided
• Non-Stop Hydraulic, Y type: -the
highest liftin
g measurement ≈: 85
cm – the highest loading 600 to
2300 kg
ü The variety of cylinder diameter
Ø (90 - 100 -110 - 125 mm).
. -- The variety of accumulator
capacity (150 bars instead of100
bars).
• Z type Non Stop hydraulics:
• P9 Non Stop mechanical:
The hydraulic controling
units of the plough
- The variety of accumulator
capacity (150 bars instead of100
bars).
• 2 or 3 functions of hydraulic
clitch with controling (grey box) or
Cobra lever. .
• Simple coupler
Bearing wheels • Ø 880 mm pneumatic (400/60-
15.5); ELS profil.
• 880mm Ø wheel (400/55-17.5)
BP profil : 414.
• 1000 mm Ø wheel (500/60-15.5)
500 mm
width ELS.
• 1080 mm Ø wheel (400/70-R20)
415 mm
width FS24.
• 1115 mm Ø wheel adhesive
(16.0/70-20)
• 1220 mm Ø wheel (17.5/24)
radial, 114 cm plou
gh bottom
distance.
