3 Structure
The structure of a retrofit seat is shown here using the example of a Vario F (0841124) without and with e-package.
Fig. 11 Structure of the seat
1. Seat length adjustment (option)
2. Seat depth adjustment
3. 4-way lumbar support curvature adjustment
4. Headrest
5. Release folding backrest - both sides (option)
6. Side bolster adjustment in backrest
7. Baggage net (option)
8. 4-way lumbar support height adjustment
9. Backrest inclination adjustment - both sides
10. Operating panel - e-package (left or right)
