SKU 65761 For technical questions, please call 1-800-444-3353. Page 32
CONTROL SYSTEM PARTS LIST & DIAGRAM
Part # Description Qty
1M Bolt 2
2M Governor Spring 1
3M Bolt 1
4M Governor Arm 1
5M Nut 1
6M Throttle Return Spring 1
7M Governor Rod 1
8M Control Assembly 1
9M Nut 1
10M Fixing Plate 1
11M Washer 1
Part # Description Qty
12M Washer 1
13M Retainer Assembly 1
14M Spring 1
15M Screw M5x35
16M Cable Return Spring 1
17M Control Handle 1
18M Screw M5x25 1
19M Back Plate 1
20M Screw M4x6 1
21M Locking Ring 1
22M Clip 1
Note: When ordering replacement parts from this diagram, use the sufx “M”.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
