SKU 65761 For technical questions, please call 1-800-444-3353. Page 33
AIR CLEANER PARTS LIST & DIAGRAM
Part # Description Qty
1N Air Cleaner Assembly 1
2N Elbow 1
3N Short Collar 2
4N Long Collar 2
5N Elbow Packing 1
6N Bolt 6x20 1
7N Nut 6mm 2
8N Nut 2
9N Air Cleaner Cover 1
Part # Description Qty
10N Air Cleaner Element Assembly 1
11N Grommet 1
12N Outer Filter 1
13N Element 1
14N Noise Silencer 1
15N Air Cleaner Assembly 1
16N Cover 1
17N Screw 2
Note: When ordering replacement parts from this diagram, use the sufx “N”.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
