Page 12SKU 97079 For technical questions, please call 1-800-444-3353.
schedule explained in the MAINTE-
NANCE AND SERVICING section.
Equipment Operation
To power 120 VAC tools and applianc-1.
es, plug its Power Cord(s) into one or
both of the 120 VAC Outlets (141) of
the Generator. When nished using
the tool(s)/appliance(s), disconnect
the Power Cord(s) from the 120 VAC
Outlet(s). (See Figure F.)
To power a 12 VDC tool or appliance, 2.
plug its Power Cord into the 12 VDC
Outlet (143) of the Generator. When
nished using the tool/appliance, dis-
connect the Power Cord from the 12
VDC Outlet. (See Figure F.)
NOTE: 3. This Generator is equipped
with a 120 VAC Circuit Breaker (144)
and a 12 VDC Circuit Breaker (144).
In the event of a circuit overload, the
Generator will automatically shut off
electrical power to the appropriate
Outlet (141, 143). In this case, turn
off the Ignition Switch (145). Wait
approximately ve minutes. Press
the appropriate Circuit Breaker. Then
restart the Engine. (See Figure F.)
To prevent accidents, turn off the En-4.
gine and remove its Spark Plug Cap
(157) after use. Wait for the Engine to
cool, clean external parts with clean
cloth, then store the equipment out of
children’s reach according to the stor-
age instructions in this manual.
TECHNICAL SPECIFICATIONS
Engine Type
4 HP
4 Stroke OHV
Single Cylinder
Air Cooled
Recoil Start
Displacement 118cc
Engine Family 7CLGS.1191CF
Generator Output
Rated: 1400 Watts
Maximum: 1600 Watts
Spark Plug Type/Gap
NGK
®
6RTCU
0.028” to 0.031”
Continuous Run Time
at 50% Load
7.5 Hrs.
Low Oil Shutdown
Capability
Yes
Fuel
Type
89+ octane unleaded
gasoline
Capacity 1.98 Gallons
Engine Oil
Type
SAE 30W
(above 32° F)
SAE 5W-30
(at 32° F or below)
Capacity 20 Ounces
Receptacles
120 VAC (Qty. 2)
12 VDC (Qty. 1)
Overload Protection
15 Amp Circuit
Breakers (Qty. 2)
SERVICING
Risk of serious
personal injury
from accidental starting. Turn
the Ignition Switch (145) of the
Generator to its “OFF”
position, wait for the engine to
cool, and remove the Spark
Plug Cap (157) before
performing any inspection,
maintenance, or cleaning
procedures.
Damaged equipment can fail,
causing serious personal
injury. Do not use damaged
equipment. If abnormal noise,
WARNING
REV 09f
