Page 18SKU 97079 For technical questions, please call 1-800-444-3353.
Part # Description Qty.
65 Screw 1
66 Carburetor assy. 1
67 Air cleaner gasket 1
68 Air cleaner housing 1
69 Filter element 1
70 Filter Support 1
71 Air cleaner cover 1
72 Bolt 2
73 Nut M6 2
74 Bolt M6×30 3
75 Set pinφ8.7×φ6.2×19 2
76 Support panel 1
77 Drain plug 2
78 Washer 2
79 Bearing 62/22 1
80 Oil seal, crankshaft 1
81 Crankcase 1
82 Regulating sway bar 1
83 Washer 1
84 Split pin 1
85 Regulating shaft 1
86 Snap ring 1
87 Washer, driven gear 1
88 Driven gear, regulator 1
89 Pin 2
90 Flying block 2
91 Driven gear, regulator
assy
1
92 Washer 1
93 Sliding sleeve 1
94 Extension spring 1
95 Camshaft Assy 1
96 Tappet 2
97 Woodruff key 1
98 Drive gear
99 Crankshaft 1
100 Timing driving gear 1
Part # Description Qty.
101 Crankshaf assy. 1
102 Shank 1
103 Connecting rod cover 1
104 Bolt 2
105 Connecting rod 1
106 Piston pin circlip 2
107 Piston 1
108 Piston pin 1
109 Piston ring (Ⅰ) 1
110 Piston ring (Ⅰ) 1
111 Side rail 2
112 Expander 1
113 Scraper ring set 1
114 Piston ring set 1
115 Gasket, crankcase 1
116 Bearing 62/22 1
117 Set pin 2
118 Crankcase cover 1
119 Oil seal, crankshaft 1
120 Seal 1
121 Dipstick 1
122 Dipstick with seal 1
123 Bolt M6×28 7
124 Washer 1
125 Right cover, generator 1
126 Rotor Assy 1
127 Bearing 6204-2ZN 1
128 Stator Assy 1
129 Washer 1
130 Generator support panel 1
131 Nut M6 4
132 Bottom rubber 4
133 Bolt M6×25 4
134 Stay, generator 1
135 Washer 6mm 1
136 Bolt, M10×26 4
137 Bolt, M10×265 1
