Clutch modes and bite-point adjustment

To make the most out of the dual clutches installed, they need to be set-up to your

liking and intended use.

Mode selection

We offer multiple modes for different uses. This can be changed on the ﬂy on the

wheel itself. The three modes are:

• Dual-clutch: The 2 clutch paddles are working as 1 analog input. Left-side is the

adjustable bite-point clutch and the right-side clutch is the master.

Bite-point adjustment available ONLY in this mode.

• Analog: The 2 clutch paddles are working as 2 separate analog inputs.

• Switch: The 2 clutch paddles are working as a momentary switch.

To switch modes, Press and Hold the ADJUST (A) button and Press the mode of

your choice. (1) Dual-Clutch, (2) Analog, (3) Switch. Release both buttons after you

have made a selection.
