Grill Zone SRGG41207 - How to Replace Main Burner; Step 1: Line Up Burner and Nozzle; Step 2: Assemble Ignition Hole; Step 3: Secure Burner and Supporter

30
HOW TO REPLACE MAIN BURNER
Ignition hole
(upwards)
in burner imageMa
3. Line up burner and burner supporter and secure
both parts by using M5x10 bolts and M5 nuts.
Nozzle
M5 nut
1. Line up burner and nozzle.
2. Assembly ignition hole of the burner downwards.
