Exploded View
Scope of delivery
Item * Qty. Designation Item * Qty. Designation
1 1 Lid 16 1 Magnet
2 2 Cooking grill 17 2 Wheel cap
3 4 Flame tamer 18 2 Wheel bolt
4 1 Side shelf 19 1 Wheel
5 1 Barbecue unit (pre-assembled) 20 1 Leg, front left
6 1 Leg, rear right 21 1 Side burner regulator
7 2 lateral cross-struts 22 1 Regulator ring
8 1 Leg, front right 23 1 Leg, rear left
9 1 Cross bar 24 1 Side burner ignition with ignition cable
10 2 Door handle 25 1 Side burner
11 2 Side panel of bottom cabinet 26 1 Side burner table
12 2 Door hinge 27 1 Side burner support
13 1 Door, right 28 1 Rear panel of bottom cabinet
14 1 Door, left 29 2 Grease container
15 1 Suboor - - -
