V. 1.5 Volt “AA” Size Alkaline
Battery----------1pc.
W. Grease Box ----------1pc. X. Grease Tray -------- 1pc.
Y. Diagonal Bar Barrier -----1pc.
Z. Warming Rack ----------1pc.
ZA. Flame Tamers-------4pcs
ZB. Cooking Grids----------2pcs.
AA BB CC DD EE FF
Before beginning assembly, make sure all parts are present. Compare parts with package contents list
and diagram above. If any part is missing or damaged, do not attempt to assemble the product. Contact
customer service for replacement parts.
• Estimated Assembly Time: 40 minutes
• Tools Required for Assembly:
Phillips Screwdriver (not included) and Wrench (not included)
• Note: The right and left sides of the grill are designated as if you are facing the front of the grill.
HARDWARE CONTENTS - Pre-installed as noted in instructions that follow.
REF# Description QTY
AA 5/32-in. x 10-mm Truss Head Screw
36pcs.
BB 5/32-in. x 9/16-in. Truss Head Screw
2pcs.
CC 1/4-in. x 15-mm Truss Head Screw with washer 18pcs.
DD 1/4-in. Flat Washer
14pcs.
EE 1/4-in. Axle Flat Washer
2pcs.
FF 1/4-in. Nut
2pcs.
PREPARATION
Philli
s Screwdriver
Wrench
To Next Page
