GrillMaster 720-0737 - Assembly Instructions; Cart Assembly

9
1.
1.
1.
1. Ca
Ca
Ca
Ca rt
rt
rt
rt Assembly
Assembly
Assembly
Assembly
a) Place the Cart Caster Inset (K) into the Cart Leg,
Front Left (F) and Cart Leg, Back Left (G) .
As shown in Fig. 1.
b) Loosen, but do not remove the screws that
are pre-assembled on the Cart Leg, Front
Left (F) and Cart Leg, Back Left (G). Attach
Cart Leg, Front left (F) and Cart Leg, Back
Left (G) to Cart Frame (H) by aligning the holes
on the Cart Frame (H). Tighten the screws that
were loosened above.
Note: Make sure the flat side of Cart Frame (H)
f aces inside to the right when attaching .
As show n in Fig. 2 .
c) Loosen, but do not remove the screws that are
pre-assembled on the Cart Leg, Front Right (I)
and Cart Leg, Back Right (J). Attach Cart Leg,
Front Right (I) and Cart Leg, Back Right (J) to
Cart Frame (H), by aligning the holes on the
Cart Frame (H) . Tighten the screws that were
loosened above.
Note: Make sure the flat side of Cart Frame (H)
faces inside to the left when attaching .
As show n in Fig. 3.
ASSEMBLY
ASSEMBLY
ASSEMBLY
ASSEMBLY INSTRUCTIONS
INSTRUCTIONS
INSTRUCTIONS
INSTRUCTIONS
Fig.
Fig.
Fig.
Fig. 1
1
1
1
Fig.
Fig.
Fig.
Fig. 3
3
3
3
H
J
G
K
F
H
I
Fig.
Fig.
Fig.
Fig. 2
2
2
2
G
F
