Translation of the original instructions
TECHNICAL SPECIFICATIONS G131
ENGINE:
LOMBARDINI 3 LD 510 with electric starter. Light kit also available.
MACHINE
Clutch: active disc clutch.
Gearbox: oil-bath gears; 4 forward speeds and 2 reverse (walking tractor version) - 2 forward
speeds and 2 reverse (sickle bar version).
Speeds in km/h (mph) with engine at 3000 rpm are the following:
Gears Speeds with tyres 5.00-12 Speeds with tyres 6.5/80-12
1st
2nd
3rd
4th
1st REVERSE
2nd REVERSE
1,2
2,4
3,4
7,1
1,7
3,5
1,3
2,5
3,5
7,3
1,8
3,6
PTO: upper synchronized PTO (on demand) - lower PTO at 1028 rpm clockwise with engine at
3000 rpm.
Reverse Speed Interference: a safety device which prevents the engagement of the reverse
speed if the PTO is engaged (machine in walking tractor version).
Wheels: Tires 5.00-12 and 6.5/80-12 and steel wheels 46x12 cm.
Differential gear: with lock device on the handlebar.
Handlebar: reversible with height and side adjustment.
Rotary tiller: standard 70 cm, adjustable at 55 cm and 85 cm.
Weight: with rotary tiller and diesel engine 215 kg.
Attachments: rotary tiller and wheel extensions, steel wheels, rotary tiller wheel, plough frame,
single furrow plough, turn-wrest plough, adjustabel furrower or furrower behind the rotary tiller,
potato lifter, cutting bar, towed trailer, brakes kit, wheel weights, all purpose flail, snow balde,
pivonting brush, snow thrower, stone burier, rotary plough, power harrow.
PUTTING THE MACHINE INTO SERVICE
1) Check that the machine has not been damaged during transport.
2) Remove the machine from its packaging, paying attention not to damage levers and wires.
Using a lifting machine of appropriate lifting capacity (min. 300 kg). Before leaning the machine
onto the ground mount the wheels and make sure the fixing nuts are firmly tightened (fig. 2, n. 6).
3) The machine is delivered with the handlebar positioned in sickle-bar version (bent over the
engine). To put the handlebar in walking tactor version press the lever (fig. 1, n. 2) and slowly turn
the handlebar 180° clockwise, paying attention not to damage the wires. Then insert the control
levers (fig. 1, n. 3 – 12 – 13 15).
Important: the control levers delivered standard with the machine are those necessary for the
walking tractor version. If the machine is to be used in sickle-bar version the appropriate lever kit is
needed.
4) Before mounting the attachment thoroughly grease the machine PTO flange. Then mount the
attachment (e.g. rotary tiller, cutting bar…) and tightly fasten the fixing nuts (fig. 3, n. 7).
5) Add engine oil – always refer to the attached instruction manual. The engine oil cap is located
under the engine hood.
6) Check the gearbox oil level (cap – fig. 4, n. 16). Use 80W90 oil (international ref. API GL5, US
MIL-L- 2105D).
7) Add oil into the air filter, use the same oil as for the engine (fig. 1, n. 10).
