Translation of the original instructions
WALKING TRACTOR VERSION:
SPEED
POS. A + RID 1° FORWARD
POS. B + RID 2° FORWARD
POS. A + VEL 3° FORWARD
POS. B + VEL 4° FORWARD
POS. A + RM 1° REVERSE
POS. B + RM 2° REVERSE
SICKLE-BAR VERSION:
SPEED
POS. A + RM 1° FORWARD
POS. B + RM 2° FORWARD
POS. A + RID 1° REVERSE
POS. B+ RID 2° REVERSE
To start the machine, choose the speed using the lever on the gearbox on the right side of the
handlebar (fig. 1, n. 13), then choose either the fast or slow gear using the outer lever located next
to the previous one (fig. 1, n. 3). The machine will start moving by pressing the grey safety lock
device (fig. 1, n. 21) and subsequently pressing the red clutch lever (fig. 1, n. 1).
IMPORTANT: Before pressing the clutch red lever to start the machine always check which
gear is engaged, if the forward gear or the reverse gear (see label fig. 1).
If the gear does not immediately engage, do not strain the lever: engage and disengage the clutch
repeatedly and very slightly until the gear is engaged.
When releasing the red lever (fig. 1, n. 1) the machine stops immediately while the engine keeps
on running and the red clutch levercomes back into vertical position.
STARTING WORK (walking tractor version)
Push forward the grey PTO lever (fig. 1, n. 15) until it is locked to engage the rotary tiller. If the tiller
does not immediately engage, do not strain the lever: engage and disengage the clutch repeatedly
and very slightly until the tiller is engaged.
CAUTION: When the tiller is on never put your hands and feet under the hood and do not
open the tiller door. This door must be kept adherent to the ground to ensure a safe use of
this machine.
NOTE: to avoid problems to the clutch during the functioning of the machine, please keep the red
lever firmly depressed. Important: Do not use the machine whilst only partially depressing the red
lever.
To disengage the rotary tiller pull the PTO lever (fig. 1, n. 15).
REVERSE GEAR (walking tractor version)
To engage the reverse gear in walking tractor version, pull the outer red lever (fig. 1, n. 3) which is
located on the right side of the handlebar. If the gear does not immediately engage, do not strain
the lever: engage and disengage the clutch repeatedly and very slightly until the gear is engaged.
IMPORTANT: Before pressing the clutch red lever to start the machine always check which
gear is engaged, if the forward gear or the reverse gear (see label fig. 1).
