13 Accessory
13.1 Sensor for temperature and humidity (model 1.153FH180)
This sensor is necessary for the standard cubic meter correction.
Size: Diameter 15mm, length 130mm, cable ca. 2m
Plug: 6 pin
Power supply: 10V +-5% < 5mA
Temperature range: -20° to +50°C
Resolution: 0.1K
Accuracy: typ. 0.3K
Humidity range: 0 to 100% r.H.
Resolution: 0.1%
Accuracy: typ. 1%
Chart 2: Specifications 1.153
13.2 Analog adapter for PM 10 + PM 2.5 and PM 1 (model 160)
This adapter has to be connected via the RS-232 socket. The digital PM output values will be converted
into analog signal from 4mA up to 20mA. The PM values will be refreshed within the set interval. The unit
measures 11x7x2 cm (4,5x2,5x0,8 inches) and is self-power-supplied with 18VDC and 40mA.
13.3 Memo card reader (model 1155B)
If you do not want to read out the data on location, you can use the card reader model 1155B. This device
has all functions of the RS-232 interface which are necessary for the storage card. With the corresponding
software it is possible to read out the data ten times faster. Reading out the data of a full 1MB storage
card thus reduces from about 1.5 hours to only 10 minutes.
