Title:
48V Lithium 48V Lithium 48V Lithium 48V LiFePO4 48V LiFePO4
Subtitle:
Fast Charge Stnd Charge 80% Charge Fast Charge Stnd Charge
Bulk Amps:
7.0 A 4.0 A 4.0 A 7.0 A 4.0 A
Full Volts:
54.5 V 54.5 V 52.6 V 57.6 V 57.6 V
If none of the presets are appropriate for your battery, then you have the option to add a custom
profile as well with the Create New Profile screen at the end of the list. Custom profile creation is
detailed in Section 2.1.3.
1.3. Charging Process
With just one profile active, the Satiator will start charging the battery whenever it is connected
to a pack that isn't fully charged. If there is no battery attached, the display screen will say
CONNECT BATTERY along with a summary of the charge profile. Once it detects a pack has been
plugged in, then the charger will automatically start the charge process, and the display will
show the charging status in real time.
Figure 6: Display screen before battery connected and after start of charge cycle
The ability to see the actual amp-hours put into the pack can be of great value in understanding
the health of a battery system and allowing the user to rest confident that it has received a full
charge.
A title bar across the top provides additional information, including the output watts, the casing
temperature, and the target full charge voltage. The target voltage is useful to confirm that the
correct profile is selected even after the charge process has begun. In the case of NiCad / NiMH
batteries, the title bar will also show the battery temperature and the remaining top-up time
during top up mode (see section 4.3)
Title:
24V SLA 36V SLA 48V SLA
Subtitle:
Fast Charge Stnd Charge Stnd Charge
Bulk Amps:
8.0 A 4.0 A 4.0 A
Full Volts:
28.8 43.2 57.6
Float Volts
27.0 40.5 54.0
