Model G2790 (Mfd. Since 04/13)
Box 1 Contents (Figure 5) Qty
A. Grinding Assembly w/Pivot Support ........... 1
B.
Wheel Dressing Stone ............................... 1
C. Wheel Dressing Tool Holder ...................... 1
D.
Star Knobs
1
⁄4"-20 x
1
⁄2"............................... 2
E.
Flat Washers
1
⁄4" ......................................... 2
F.
Adjustable Guard ........................................ 1
G.
Star Knobs
1
⁄4"-20 x 2
3
⁄4" ............................. 5
H.
Star Knobs
1
⁄4"-20 x
7
⁄8" ............................... 5
I. O-Rings 6 x 2mm ....................................... 5
J.
Hex Nuts
1
⁄4"-20 .......................................... 5
Box 2 Contents (Figure 6) Qty
K. Slide Table .................................................. 1
L.
Slide Bar ..................................................... 1
M. Knife Clamp ................................................ 1
Figure 5. Box 1 inventory.
A
B
C
D
E
F
G H
I
J
K
L
M
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
Inventory
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Figure 6. Box 2 inventory.
