Page #11 background imageLoading...
Page #11 background image
1
Call 1-800/676-9040 for Technical Support
3
INSTALLING, CLEANING AND TESTING
WARNING
GROUNDING INSTRUCTIONS
This appliance must be connected
to a grounded metallic, permanent
wiring system, or an equipment
grounding conductor must be run
with the circuit conductors and
connected to the equipment
grounding terminal on the station.
3.1 Installation and Start-up
CAUTION
DO NOT INSTALL THE UNIT WITHIN
2 INCHES OF A HEAT SOURCE
(SUCH AS A BRAISING PAN, DEEP FAT
FRYER, CHARBROILER, OR KETTLE).
Electrical Supply Connection Observe all local, national, or
other applicable codes.
Three phrase models of the Vortex® Connectionless Steamer are
supplied with a cord set ready to be connected to a power
supply. See the chart below for the correct matching receptacle
(not supplied with the unit).
Single phase models are designed to be directly connected (hard
wired) to the electrical supply. Allow sufficient loop in the flexible
conduit to facilitate inspection, servicing, and cleaning.
Branch Circuit Protection
Each Steamer, including individual units of stacked models,
should have its own branch circuit protection and ground wire.
Current and power demands for each unit are as shown below.
Field Wiring Table
Use copper wire only – insulation rating 90°C
Voltage Phase Rated Current
60 hz only Demand (amps)
VRC-3E VRC-6E
208 3 25 34
240 3 22 29
480 3 11 25
208 1 44 58
240 1 38 50
Plug & Receptacle Chart
Three Phase Only
Volts Phase Plug Receptacle
9 KW 12 KW 9 KW 12 KW
208 3 15-50P 15-50P 15-50R 15-50R
240 3 15-30P 15-50P 15-30R 15-50R
480 3 L16-20P CS8165C L16-20R CS8169
Hubbel or Hubbel or
Equivalent Equivalent
