Growatt GroBoost User Manual

21
in Figure 5.1, the pairing light ④of the host flashes quickly, they are
pairing;
⚫ STEP3
The GroBoost LED3 light does not flash, the host (ShineLanBox) pairing
light ④ is off, the device light ③ flashes, and the pairing is successful;
Note:
The flash number of times of the ShineLanBox device light③ means the
number of devices connected to ShineLanBox.
Figure 3-6
四、Device parameters
The equipment specifications are shown in Table 4-1
category
Item
Parameter
General
Dimension (W/H/D)
288mm *227mm *101mm
Weigh
3.5kg
User manual
Chinese and English
Power Supply
230Vac/3*230Vac 50Hz
Working current
25MA
Power consumption
5W
Maximum load power
3.6kW/10.8kW (Single channel
adjustable)
Operating Temperature
-25℃ ～ +60℃
A B
