Growatt INFINITY 1300 - Expansion and Specifications; Expansion, Specifications, and FAQ

Precautions before using the UPS feature
1. This function is a non-professional UPS function and does not support 0ms switching. Please do not connect it to equipment that is highly sensitive to
uninterrupted power supply, or perform multiple tests before use.
2. UPS only supports the use of electrical appliances below 1800W, and do not use other devices at the same time during use to avoid OVERLOAD
protection.
3. UPS function is only supported when one INFINITY 1300 is running independently, and it is not available when multiple INFINITY 1300s work in series.
4. Growatt is not responsible for equipment failure or loss of data if the instructions are not followed.
II) Multi-unit Expansion in Series
You can use AC adapters to connect up to three INFINITY 1300 in series to get a larger battery capacity.
When you use this expansion method, you will need to define one of the units as the master and the rest as slaves. You need to connect the AC output port of
the master unit to the AC input port of Slave 1, then connect the AC output port of Slave 1 to the AC input port of Slave 2, then plug the load device into the AC
output port of Slave 2(as shown in the figure below), and finally turn on the AC output power of all INFINITY 1300 to enable battery expansion.
When using this expansion method, make sure that each units are fully charged, otherwise an overload protection will be triggered. After use, it is
recommended to charge each unit separately to avoid excessive burden on the home grid.
1 2 3
General
Input Ports
Weight
42.33lbs (19.2KG)
AC Charger
1200W MAX
Dimensions (Lx W x H)
16.5*8.4*11in (41.8*21.4*28.0cm)
AC Input Voltage
100V-120Vac, 60Hz
Capacities
51.2V*27Ah（1382wh）
DC Charger
12-24Vdc/8A MAX
Certifications
FCC,CE,ETL
Output Ports
Battery Information
AC Output（X4）
Full Sine Wave
1800W（surge 3600W）total
120Vac（60Hz）/（50Hz）
Cell Chemistry
Lithium-ion
Discharge Temperature
-10°C ~ 45°C
USB-A（X2）
5VDC,2.4A,12W MAX
Charge Temperature
0℃ ~ 45℃
USB-A Fast Charge（X2
5V/2.4A,9V/2A,12V/1.5A 18W MAX
Optimal Operating Temperature
10℃ ~ 28℃
USB-C（X2）
5V,9V,12V,15V,20V/5A 100W MAX
Shelf Life
1 Year（after fully charge）
Car Charger（X2）
13.2V/10A 132W MAX
Lifecycle
3000 Cycles/80%
Can I take INFINITY 1300 on a plane?
No, you can’t. This product is a lithium battery product. According to international air transport regulations, lithium battery products exceeding 100Wh cannot be
carried on the plane.
Why does the Infinity 1300 not work properly when the total output power of the device is within the rated power of the INFINITY 1300?
First, please check whether the power of the product is too low, and charge the product in time. Secondly, check that the instantaneous power of the equipment
exceeds the instantaneous peak power of INFINITY 1300. If so, you should use Growatt higher power products.
Technical Specifications
FAQ
