7.3.1 Special tools
Pos. Description For pos. Further information Part number
A Service tool for loosening and tightening shaft seal 105
For ∅22 pump shafts 99072586
For ∅28 and ∅36 pump
shafts
99072587
B Eyebolt with swivel function 51 M10 x 1.5 -
C Key for split-cone nut 48
For ∅22 pump shafts SV0004
For ∅28 pump shafts 99072584
For ∅36 pump shafts 99072585
D T-pin 51 - 99072581
E Service tool for smoothening out marks on shaft 51 - -
F Adjusting fork 105
For ∅22, ∅28 and ∅36 pump
shafts
-
G Hook for thrust-handling device 120h - 99176979
H1
Service tool for chamber stack
For vice
99081919
H2 For pump base
I Protection pipe for shaft 51
For ∅28 pump shafts
reduced to ∅22 shaft ends
99081891
For ∅36 pump shafts
reduced to ∅22 shaft ends
99081920
For ∅36 pump shafts
reduced to ∅28 shaft ends
99081890
J
Service tool for alignment of pump head, sleeve and chamber
stack
2, 51
For ∅22 pump shafts 99072588
For ∅28 pump shafts 99072589
For ∅36 pump shafts 99072590
K Punch tools for bush 47, 47c, 47d
For ∅22 pump shafts 98369955
For ∅28 and ∅36 pump
shafts
99081918
L Tool for installing neck ring 45a For CR, CRN 95 - 255 99447875
M Protective disc 48
For ∅28 pump shafts 99381867
For ∅36 pump shafts 99381868
N Screw-clamp for outer sleeve 55 - 99139064
O Pin for torque wrench 105 14 x 18 x ∅14 SV0402
P Torque wrench 105 - -
Q Hammering tool 48
For ∅28 pump shafts 99424834
For ∅36 pump shafts 99424835
