40
Product Guide
Product range
Model
JPF 2-A JPF 3-A JPF 4-A JPF 41-A JPF 5-A JPF 7-A JPS 2-A JPS 4-A JDF 2-A JDF 4
Flow range (U.S. gpm) 1.7-13 1.7-12.2 1.7-16 1.8-21 2.6-22 2.6-35 1.7-17 3.5-28.2 1.8-10.3 0.75-13.1
Max. pump head H(ft) 135 170 172 185 200 200 140 155 145 167
Max. working pressure (psi) 87 87 87 87 110 110 110 110 87 87
Motor power (hp), Nominal 1/3 1/2 3/4 1 1.5 2 1/2 1 1/2 3/4
Maximum Fluid Temperature range 14°F to 104°F (-10 to 40°C)*
Maximum lift, Ft (Sea level) 26 26 26 26 140 140 26 26 70 80
Maximum Ambient Temp 34°F to 104°F (1 to 40°C)
Factory Pressure -Switch setting (PSI) 20-40 30-50 30-50 40-60 50-70 50-80 30-50 30-50 30-50 30-50
Storage Temp 14°F to 104°F (-10 to 40°C)
Relative Humidity 95%
Maximum Starts per hour
20
*Minimum fluid temperature on water, 32°F (0°C)
Basic Line Jets
41
Product Guide
Applications
Shallowwell,DeepwellandConvertiblepumpappli-
cations.Grundfosjetpumpsareself-primingcentrifu-
galpumpssuitablefordomesticwatersupplysystems,
lightagriculturalandindustrialwatertransferapplica-
tions
Pumps
JPF2A, JPF3A, JPF4A, JPF41A Pumps:
Ruggedcastironconstruction.Single-stageshallow
wellself-primingcentrifugalpumps.Endsuction,top
dischargearrangementandTechnopolymerimpeller.
Pumphasbuilt-inejectorcompletewithcleanoutport
toclearblockagesfromnozzle.Convenientpriming
plugforeaseofprimingandairelimination.Ceramic-
Carbonbellowsmechanicalsealensurestrouble-free
operation.
JPF5A & JPF7A Pumps:
Ruggedcastironconstruction.Multistageconvertible
self-primingcentrifugalpumps.Endsuction,topdis-
chargearrangementwithdetachableejectorassembly
fordeepwellapplicationsandTechnopolymerimpel-
lers.Convenientprimingplugforeaseofprimingand
airelimination.Ceramic-Carbonbellowsmechanical
sealensurestrouble-freeoperation.
JDF2A & JDF4A Pumps:
Ruggedcastironconstruction.Single-stagedeep
wellself-primingcentrifugalpumps.Endsuction,top
dischargearrangementandTechnopolymerimpel-
ler.Pumphasseparatedeepwellportforconnection
toDeepWellejectorkit.Convenientprimingplugfor
easeofprimingandairelimination.Ceramic-Carbon
bellowsmechanicalsealensurestrouble-freeopera-
tion.
JPS2A & JPS4A Pumps:
Corrosionresistantstainlesssteelconstruction.
Singlestageshallowwellself-primingcentrifugal
pumps.Endsuction,topdischargearrangementand
Technopolymerimpeller.Ceramic-Carbonbellows
mechanicalsealensurestrouble-freeoperation.
Motors
All jet pump motors are totally enclosed and fan-
cooled design for quiet operation and superior protec-
tion in harsh environments. Stainless steel motor shaft
offers excellent corrosion resistance. Double, oversized
greased ball bearings are maintenance-free sealed for
life. All motors have built-in thermal overload protec-
tion and are capacitor-run, with no switches to fail.
Drive end motor bearing protected by durable lip seal.
InsulationclassF,motorprotectionIP44,terminalbox
protectionIP55.
Pumped Liquid
Onlyuseonclean,non-viscous,non-aggressive,non-
explosiveliquids.Pumpnottobeusedonpoolwater
applicationsorhydrocarbontransfer(i.e.diesel,gaso-
line,etc).
Agency Approvals:
CSA-StdC22.2No108,No77-95.
Mounting Position:
Shaftinhorizontalpositiononlyforallpumps.
Basic Line Jets
L-DWS-PG-01 8-09.indd 41 11/12/11 12:49 AM
