42
Product Guide
Electrical Data:
Model
Electrical Data
Voltage
60 Hz
kW
Maximum
hp
Nominal
S.F.
I
Amps
Capacitor
µF
JPF2A 115 0.65 1/3 1.75 6 40
JPF2A 230 0.65 1/3 1.75 3 10
JPF3A 115 0.85 1/2 1.6 7.5 20
JPF3A 230 0.85 1/2 1.6 3.8 12.5
JPF4A 115 1.10 3/4 1.5 10 64
JPF4A 230 1.10 3/4 1.5 5 16
JPF41A 115 1.31 1 1.4 12 80
JPF41A 230 1.31 1 1.4 6 20
JPF5A 230 1.70 1.5 1.3 8 31.5
JPF7A 230 2.40 2 1.2 11 40
JPS2A 115 0.88 1/2 1.6 7.6 50
JPS2A 230 0.82 1/2 1.6 3.7 12.5
JPS4A 115 1.6 1 1.4 13.6 80
JPS4A 230 1.53 1 1.4 7 20
JDF2A 115 0.75 1/2 1.6 7 50
JDF2A 230 0.75 1/2 1.6 3.4 12.5
JDF4A 115 0.88 3/4 1.5 8 64
JDF4A 230 0.88 3/4 1.5 4 16
Basic Line Jets
43
Product Guide
JPF 2A, 3A, 4A, 41A* Shallow Well
Materials: JPF 2A, 3A, 4A, 41A
Shallow Well
Descriptions Material
Motor Stool Cast Iron
Shaft Seal Carbon/Ceramic/NBR
O-Rings & Gaskets NBR
Base Plate Cast Iron
Pump Housing Cast Iron
Impeller Noryl©
Motor Shaft Stainless Steel AISI 416
Tubing Polyethylene
Diffuser Noryl©
Venturi Tube and Nozzle Noryl©
Note:Noryl©isaregisteredtrademarkofGeneralElectricCompany
JPF 5A, 7A Convertible*
Materials: JPF 5A, 7A
Convertible
Descriptions Material
Motor Stool Cast Iron
Shaft Seal Carbon/Ceramic/NBR
Motor Shaft Stainless Steel AISI 303
O-Rings & Gaskets NBR
Base Plate Cast Iron
Pump housing Cast Iron
Impellers Noryl©
Tubing Polyethylene
Diffuser Noryl©
Venturi Tube and Nozzle Noryl©
Note:Noryl©isaregisteredtrademarkofGeneralElectricCompany
*Available in Canada*41A available in Canada
Basic Line Jets
L-DWS-PG-01 8-09.indd 42 11/12/11 12:49 AM
