4 - 5
GRUNDIG Service Chassis D5
Ersatzteilliste
Spare Parts List
LP-CHASSISMODUL D5 21
CHASSISBOARD D5 21
TV
MATERIAL-NR. / PART NO.: 275990132400
ǵ
10 / 2004
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
275990132400 LP-CHASSISMODUL D5 21" CHASSISBOARD D5 21"
KEIN E-TEIL NO SPARRE PART
C 54 759550949200 ELKO 10 UF/16V
C 524 S 759551088300 KONDENS. 7.2NF %3.5 1600V
C 528 S 759551088400 KONDENS. 270NF J 250V R:15
C 601 S 759550949300 KONDENS. 220 NF/275 V AC
C 610 S 759880450800 KONDENS. 2.2nF 20% 250V
D 01 759551054400 LED IR SIR563SB3F 23/940
D 02 759551054500 LED LTL4221N D:3 R/D RED
D 501 759551052900 DIODE 1N4005
D 502 833021514800 MELF DIODE 1N4148
D 503 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 504 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 521 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 522 759880511100 DIODE RGP15J
D 525 833021514800 MELF DIODE 1N4148
D 601 759551053000 DIODE BYV26A-TAP
D 602 759551053000 DIODE BYV26A-TAP
D 603 833021514800 MELF DIODE 1N4148
D 621 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 622 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 623 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 624 830956550700 DIODE RGP10J/1N4937 MOT/GP
D 626 759551049400 DIODE SFAF504G
D 626 759551049400 DIODE SFAF504G
D 627 759551052500 DIODE BYW36-TAP
D 628 759551052500 DIODE BYW36-TAP
D 629 833021514800 MELF DIODE 1N4148
D 630 833021514800 MELF DIODE 1N4148
D 631 830956550700 DIODE RGP10J/1N4937 MOT/GP
DB 601 759551049900 DIODE G2SBA60
DSL 820 S 759551055100 DVD LAUFWERK MIT MPEG-MODUL
F 601 S 759550922700 SICHERUNG 3.15AT
FR 521 S 759550542900 WIDERST 0,1 OHM J 0,75W
IC 01 759551054600 IC S3C1840DA9/SMB1 T&R
IC 301 759551056300 IC TDA7266
IC 303 759551048800 IC KIA7042P AP 4.2V
IC 501 759551052600 IC LA7840
IC 601 759551048900 IC LF1352 STR-F6654R
IC 621 759551049000 IC KIA278R05PI
IC 623 759551049100 IC KIA278R33API
IC 624 759551049000 IC KIA278R05PI
IC 625 759551049500 IC KIA278R09PI
IC 626 759551049300 IC KIA78R08API
IC 627 759551049200 IC SE110N LF12
IC 628 S 759551052700 OPTOKOPPLER TCET1108G
L 302 759880625600 SPULE 22 UH
L 521 759551056700 SPULE 130UH 0.45PY 55.5TUR
L 523 759551056800 SPULE H-LIN 100UH
L 621 759551052800 SPULE 100UH 53.5T R:7.5MM
LED 1 759550931600 LED ROT
PT 601 S 759550457500 PTC 9OHM 2PIN (R607)
Q 50 759551048700 TRANS KRC102M TP (KRC1202)
R 603 S 759551088200 SICH.-WIDERST.8.2M J 1/2W
RL 601 S 759550572300 RELAY SDT-S-105LMR 5V
T 01 830220018800 TRANS BC337-25 SIE/PHI/TFK/
T 02 830100685700 SMD-TRANS.BC 857 C
T 301 759880512900 TRANS KTC3198Y
T 501 759551049600 TRANS A1980Y
T 521 759510451600 TRANS.KSC 2331 Y
T 522 759880513100 TRANS T2SD2499
T 523 759880512900 TRANS KTC3198Y
T 621 759510451600 TRANS.KSC 2331 Y
T 622 759880512900 TRANS KTC3198Y
T 623 759551013200 TRANS BF 421
T 624 759551048700 TRANS KRC102M TP (KRC1202)
TR 501 S 759551056500 TRAFO DST50005 21"
TR 522 S 759551053100 TRAFO 6170VC003A 21"
TR 602 S 759551056400 TRAFO 21" SMT50007
TR 603 S 759551049800 TRAFO STANDBY SMT50004
TR 604 S 759550945600 FILTER 18 MH
VD 601 S 759551049700 VARISTOR ILJIN 621D-14A 620
VR 601 S 759550927600 ESTR 10K
X 601 759550966400 STECKER 2 POL.
ZD 194 759540390700 Z-DIODE BZX55-C6V2
ZD 301 759540390700 Z-DIODE BZX55-C6V2
ZD 521 759550453400 Z- DIODE UZT33V
ZD 522 759540390700 Z-DIODE BZX55-C6V2
ZD 523 759550923400 DIODE BZX55C9V1
ZD 524 830972008200 Z DIODE 8,2 C 0,5W
Ersatzteilliste
Spare Parts List
LP-VIDEOMODUL D5 14"
VIDEOBOARD D5 14"
TV
MATERIAL-NR. / PART NO.: 275990135200
ǵ
12 / 2004
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
275990135200 LP-VIDEOMODUL D5 14" VIDEOBOARD D5 14"
KEIN E-TEIL NO SAPRE PART
D 101 830921504500 DIODE 1N4148 AV619 -GA
D 102 833021514800 MELF DIODE 1N4148
D 104 833021514800 MELF DIODE 1N4148
F 101 759550950100 FILTER MKT 40.4MA110P-TF01
F 102 759550921100 FILTER OFW K9656M
F 103 759551053600 SAW FILTER OFW K3958M
F 104 759550951800 FILTER TPT02B
IC 101 759551054100 IC OM8365 (96K) T&R
IC 102 759551053700 IC MC33269T-3.3V
IC 160 830584860100 SMD IC TDA8601T-C1-T3 PHI
IC 201 759551056900 IC CXA2040AQT4 QFP32P
IC 203 759550446600 IC TDA7442D
IC 401 759550542200 SMD IC M24C08N SC2.7
L 105 759813083500 DR 0207 10UH 5% AX
L 106 759813083500 DR 0207 10UH 5% AX
L 107 759813083500 DR 0207 10UH 5% AX
L 108 759813083500 DR 0207 10UH 5% AX
L 109 759880481000 SPULE 8.2UH 10%
L 160 759813083500 DR 0207 10UH 5% AX
L 191 759550452000 SPULE 50MHZ 600RPH-WB
L 192 759550452000 SPULE 50MHZ 600RPH-WB
L 201 759813083500 DR 0207 10UH 5% AX
L 202 759813083500 DR 0207 10UH 5% AX
L 203 759813083500 DR 0207 10UH 5% AX
L 204 759813083500 DR 0207 10UH 5% AX
L 210 759813083500 DR 0207 10UH 5% AX
L 260 759813083500 DR 0207 10UH 5% AX
L 290 759813083500 DR 0207 10UH 5% AX
Q 401 759550944800 QUARZ 12 MHZ
SCART1 759550922900 EURO AV BUCHSE
T 102 759551054000 TRANS KRC102S
T 103 759551054000 TRANS KRC102S
T 104 759551054000 TRANS KRC102S
T 105 759551054000 TRANS KRC102S
T 106 759551053900 TRANS 2SC3875S
T 107 759551053900 TRANS 2SC3875S
T 108 759551053900 TRANS 2SC3875S
T 109 759551054000 TRANS KRC102S
T 160 759551053800 TRANS 2SA1504S
T 161 759551053800 TRANS 2SA1504S
T 162 759551053800 TRANS 2SA1504S
T 163 759551053900 TRANS 2SC3875S
T 164 759551053900 TRANS 2SC3875S
T 165 759551053900 TRANS 2SC3875S
T 201 759551053800 TRANS 2SA1504S
T 274 759550937700 TRANS 2N7000 60V 200MA
T 275 759550937700 TRANS 2N7000 60V 200MA
TUNER 759550921600 TUNER PH PLL UV1316/AIG-4
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
