4 - 6
GRUNDIG Service Chassis D5
Ersatzteilliste
Spare Parts List
LP-VIDEOMODUL D5 21"
VIDEO BOARD D5 21"
TV
MATERIAL-NR. / PART NO.: 275990135100
ǵ
1 / 2005
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
275990135100 LP-VIDEOMODUL D5 21" VIDEO BOARD D5 21"
KEIN E-TEIL NO SPARE PART
C 113 759550949200 ELKO 10 UF/16V
C 131 759550949200 ELKO 10 UF/16V
C 133 759550949200 ELKO 10 UF/16V
C 232 759550949200 ELKO 10 UF/16V
C 239 759550949200 ELKO 10 UF/16V
C 241 759550949200 ELKO 10 UF/16V
C 248 759550949200 ELKO 10 UF/16V
C 249 759550949200 ELKO 10 UF/16V
C 265 759550949200 ELKO 10 UF/16V
C 290 759550949200 ELKO 10 UF/16V
C 407 759550949200 ELKO 10 UF/16V
D 101 830921504500 DIODE 1N4148 AV619 -GA
D 102 833021514800 MELF DIODE 1N4148
D 104 833021514800 MELF DIODE 1N4148
F 101 759550950100 FILTER MKT 40.4MA110P-TF01
F 102 759550921100 FILTER OFW K9656M
F 103 759551053600 SAW FILTER OFW K3958M
F 104 759550951800 FILTER TPT02B
IC 101 759551054100 IC OM8365 (96K) T&R
IC 102 759551053700 IC MC33269T-3.3V
IC 160 830584860100 SMD IC TDA8601T-C1-T3 PHI
IC 201 759551056900 IC CXA2040AQT4 QFP32P
IC 202 759880683500 IC MSP3410G-B8
IC 401 759550542200 SMD IC M24C08N SC2.7
L 105 759813083500 DR 0207 10UH 5% AX
L 106 759813083500 DR 0207 10UH 5% AX
L 107 759813083500 DR 0207 10UH 5% AX
L 108 759813083500 DR 0207 10UH 5% AX
L 109 759880481000 SPULE 8.2UH 10%
L 160 759813083500 DR 0207 10UH 5% AX
L 201 759813083500 DR 0207 10UH 5% AX
L 202 759813083500 DR 0207 10UH 5% AX
L 203 759813083500 DR 0207 10UH 5% AX
L 204 759813083500 DR 0207 10UH 5% AX
L 206 759813083500 DR 0207 10UH 5% AX
L 207 759813083500 DR 0207 10UH 5% AX
L 208 759813083500 DR 0207 10UH 5% AX
L 209 759813083500 DR 0207 10UH 5% AX
L 210 759813083500 DR 0207 10UH 5% AX
L 211 759813083500 DR 0207 10UH 5% AX
L 212 759813083500 DR 0207 10UH 5% AX
L 213 759813083500 DR 0207 10UH 5% AX
L 214 759813083500 DR 0207 10UH 5% AX
L 215 759813083500 DR 0207 10UH 5% AX
L 261 759904001800 SPULE 18UH 5% LAL04 AX
L 262 759904001800 SPULE 18UH 5% LAL04 AX
L 263 759904001800 SPULE 18UH 5% LAL04 AX
L 290 759813083500 DR 0207 10UH 5% AX
Q 201 759550926200 QUARZ 18.432 MHZ
Q 401 759550944800 QUARZ 12 MHZ
SCART 1 759550922900 EURO AV BUCHSE
SCART 2 759550922900 EURO AV BUCHSE
T 102 759551054000 TRANS KRC102S
T 103 759551054000 TRANS KRC102S
T 104 759551054000 TRANS KRC102S
T 105 759551054000 TRANS KRC102S
T 106 759551053900 TRANS 2SC3875S
T 107 759551053900 TRANS 2SC3875S
T 108 759551053900 TRANS 2SC3875S
T 109 759551054000 TRANS KRC102S
T 160 759551053800 TRANS 2SA1504S
T 161 759551053800 TRANS 2SA1504S
T 162 759551053800 TRANS 2SA1504S
T 163 759551053900 TRANS 2SC3875S
T 164 759551053900 TRANS 2SC3875S
T 165 759551053900 TRANS 2SC3875S
T 201 759551053800 TRANS 2SA1504S
T 202 759551053800 TRANS 2SA1504S
T 203 759551053800 TRANS 2SA1504S
T 204 759551053800 TRANS 2SA1504S
T 270 759880513300 TRANS KTA1266Y (TP)
T 271 759880513300 TRANS KTA1266Y (TP)
T 272 759880513300 TRANS KTA1266Y (TP)
T 273 759880513300 TRANS KTA1266Y (TP)
T 401 759551054000 TRANS KRC102S
TUNER 759550921600 TUNER PH PLL UV1316/AIG-4
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
Ersatzteilliste
Spare Parts List
LP-BILDROHRMODUL D5 14"
CRT-BOARD D5 14"
TV
MATERIAL-NR. / PART NO.: 275990135300
ǵ
1 / 2005
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
275990135300 LP-BILDROHRMODUL D5 14" CRT-BOARD D5 14"
KEIN E-TEIL NO SPARE PART
C 702
S 759550949500 KONDENS 100NF/250 V
D 701 830920002100 DIODE BAV21 ITT/ TFK AV619
D 702 830920002100 DIODE BAV21 ITT/ TFK AV619
D 703 830920002100 DIODE BAV21 ITT/ TFK AV619
D 704 759550975100 DIODE 1 N 4004
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
IC 701 830533610800 IC TDA6108JF SOT111-1 PHI
X 703 S 759550989300 BILDROEHRENSOCKEL
ZD 704 830972007500 Z-DIODE 7,5V/BZW SIE/ZPY IT
Ersatzteilliste
Spare Parts List
LP-BILDROHRMODUL D5 21"
CRT-BOARD D5 21"
TV
MATERIAL-NR. / PART NO.: 275990135400
ǵ
1 / 2005
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
275990135400 LP-BILDROHRMODUL D5 21" CRT-BOARD D5 21"
KEIN E-TEIL NO SPARE PART
C 702 S 759550949500 KONDENS 100NF/250 V
D 701 830920002100 DIODE BAV21 ITT/ TFK AV619
D 702 830920002100 DIODE BAV21 ITT/ TFK AV619
D 703 830920002100 DIODE BAV21 ITT/ TFK AV619
D 704 759550975100 DIODE 1 N 4004
FR 701 S 759550458400 WIDERST 0,68OHM1W
IC 701 830533610800 IC TDA6108JF SOT111-1 PHI
X 703 S 759550581000 BILDROHRFASSUNG ISHMO5S
ZD 704 830972007500 Z-DIODE 7,5V/BZW SIE/ZPY IT
