ENGLISH
9
Chapter 1 Introducing the LCD TV
Screws size:M4 X 12mm
Please note there are different sizes of fixing screws for fixing the speaker and stand:
* First secure the speaker pod to the TV using supplied four M4 X 12mm screws
* Next secure the base to the TV using the supplied 6 screws. Note that the M5 X 15mm
length screws are used at the top of the stand and the M5 X 30mm length screws are
used at the bottom of the stand.
Please note there are different sizes of fixing screws for fixing the speakers and stands:
* First secure the speaker pod to the TV using supplied four M4 X 12mm screws
* Next secure the base to the TV using the supplied 6 M5 X22mm screws.
Screws size:M5 X 30mm Screws size:M5 X 15mm
GLCD3201
Screws size:M4 X 12mm Screws size:M5 X 22mm Screws size:M5 X 22mm
GLCD3701/GLCD4001
The RCA sockets on the left & right sides of the rear of TV are used for connecting the
external speakers
