15
2
Initial Setup
Power Supply 12V DC
Current consumption 70mA
Current consumption with load (max) 100mA
Relay Contact Rating 5 Amps /240V ac
Operating Temperature -20 C to +60 C
Moisture Resistance IP 67
Dimensions - Flush Mount W. 87mm D. 21mm H. 119mm
- Surface Mount W. 87mm D. 35mm H. 119mm
Number of Users 30000
Technical Specs
Initial Installation
The Door Control should be Factory Defaulted after installation. This will restore all
default settings to the Door Control and will unenrol it from any existing GSD
Controller.
The Door Control will then start to scan and enrol on a GSD controller.
Refer to the section ‘Enrolling Door Controls’ on page 12 for instructions on how to
configure the GSD Windows Software.
Installation Notes
