34 PNEG-900 Series 2000 Autoflow Fan/Heater and Control Installation Instructions
4. Electrical Power Supply
Conduit Runs
Control Wires
Run #1 Autoflow control box to master fan/heater control box.
Five (5) - Control wires 16 gauge minimum. (NOTE: A shielded two (2) conductor 16 gauge cable
should be used for the network connections.)
Run #2 Autoflow control box to actuator control box.
Five (5) - Control wires 16 gauge minimum.
Run #3 Autoflow control box to wet supply rotary switch.
Four (4) - Control wires 16 gauge minimum.
Run #4 Autoflow control box to storage chamber rotary switch.
Five (5) - Control wires 16 gauge minimum.
Run #5 Autoflow control box to drying chamber rotary switches.
Six (6) - Control wires 16 gauge minimum.
Run #6 Autoflow control box to fill system control box (if applicable).
Eleven (11) - Control wires 16 gauge minimum.
Run #7 Master fan/heater control box to slave fan/heater control box.
Four (4) - Control wires 16 gauge minimum. (NOTE: A shielded two (2) conductor 16 gauge cable
should be used for the network connections.)
Run #8 Slave fan/heater #1 control box to slave fan/heater #2 control box.
Four (4) - Control wires 16 gauge minimum. (NOTE: A shielded two (2) conductor 16 gauge cable
should be used for the network connections.)
Power/Motor Wires
Run #1 Entrance panel to master fan/heater control box (for fan motor).
Run #2 Entrance panel to slave fan/heater control boxes (if applicable, for fan motor).
Run #3 Entrance panel to fill system control box (if applicable).
1. For fill system #1 motor starter.
2. For fill system #2 motor starter (if applicable).
3. For aeration fan motor starter.
Run #4 Fill system control box to fill system #1 motor.
Run #5 Fill system control box to fill system #2 motor (if applicable).
Run #6 Fill system control box to aeration fan motor.
Run #7 Entrance panel to actuator control box.
1. 110V AC, 110V N, Ground wire for battery charger.
To Next Page
