1010
50mm
40mm
There are two cutting heights. To change from
one to the other, engage the safety switch and
remove the battery, then turn the mower over.
Pull the axle away from the blade and guide it
into the other position.
The spring will keep the axle in position.
The cutting heights are 40mm and 50mm. Ensure both wheels on both axes are on the
same setting.
Adjusting the cutting height
WARNING: to reduce risk of personal injury, wait for the blade to stop rotating and
remove the safety key and battery before adjusting the cutting height.
