77
Insert the handle into the mower main unit,
ensuring it is the right way up.
When the pole is fully inserted, the button (1)
will pop up into the aperture (2).
Insert the battery which will click into place.
The shapes need to match
or the handle will not fit.
1
2
back view
Assembly
Push the green button to adjust the handle to
suit your requirements.
4969_MiniMower_manual_aw.indd 74969_MiniMower_manual_aw.indd 7 08/07/2021 10:2008/07/2021 10:20
