Guardall RX16i - Appendix C - Access Log Messages

PX/QX/RX Version 4.20 User Manual – Issue B
- 38 -
Alarm & Event Log messages
Log Text Additional Data Display Text Event Description
Sndr Tamper NONE NONE Panel sounder tamper
Soak Alarm Circuit nnn Cctnnn
A
circuit on soak test has
alarmed
Soak Failed Circuit nnn Cctnnn
A
t the end of the soak period
any circuit which has alarmed is
logged as failed
Soak Off Circuit nnn Cctnnn
A
circuit has been taken off soak
Soak On Circuit nnn Cctnnn
A
circuit has been put on soak
Software Error N N
A
software error has been
logged
Tamper n n Concentrator Tamper
Tamper Circuit nnn Cctnnn
A
circuit tampe
r
Tamper Keypad n KPn
A
keypad tampe
r
Tamper SM n SMn
A
serial module tampe
r
Tamper OPM n OPMn
A
n output module tampe
r
Tamper
A
CM n
A
CMn
A
n ACM tamper
Tamper Radio module number RM nn Radio Module tamper
Temp Bypass Circuit nnn Cctnnn
A
circuit has been temporarily
(until clear) bypassed
TX Off N N TX channel N off
TX On N N TX channel N on
Unset User nn, Area m Usnn Am
A
user has unset the area
Unset User nn, Group m Usnn m Group has been unset by a user
Unset Req. Circuit nnn Cctnnn Key type circuit clears
Unset Req. User nn, Keypad m Usnn, KPm
A
user requested unset on a
keypad (dual unset or unset
delay programmed)
Upload Fail GSRx GSRx Upload to GSR x failed
Upload OK GSRx GSRx Upload to GSR x OK
Verify Alm
A
rea n
A
n
A
verified alarm has occurred
Watchdog NONE NONE Software watchdog active
Appendix C – Access Log Messages
Access Control log only messages
Log Text Additional Data Display Text Event Description
A
ccess User nn, ACM m Usnn, ACMm User accessed ACM m
Card Exit User nn, ACM m Usnn, ACMm User exit by ACM m, which has
no door contact
Denied User nn, ACM m Usnn, ACMm User denied access ACM m
Door Open
A
CM m
A
CMm
A
CM door held open
Exit User nn, ACM m Usnn, ACMm User exit by ACM m
Forced
A
CM m
A
CMm
A
CM door forced open
Lock
A
CM m
A
CMm
A
CM door lock
Pending
A
CM m
A
CMm Schedule unlock pending
RTE
A
CM m
A
CMm
A
CM Door RTE button active
Set Req. User nn, ACM m Usnn, ACMm User request to set from ACM m
Unlock
A
CM m
A
CMm
A
CM door unlocked
Unset Req. User nn, ACM m Usnn, ACMm User request to unset from ACM
m
