Scope of Delivery
GSE 550 DSG # 4058
Fig. 1
1. Gene
rator
2. Battery
(not included in th
e
supp
ly – can be received in
an
auth
orised shop
)
3.
On/off / Electric starting
4. Oil replenishment plug
5. Voltmeter
6.
Overloading prot
ection 400 V
7.
400 V / 230 V switch
8.
230 V overheatin
g fuse
9. Decompression
button
10.
400 V CEE 16 co
nnection
11. 230 V Schuko connection
12.
12 V overheating
fuse
13. 12 V connection
14. Grou
nding termi
nal
15. Tank lid
16. Exhaust
17. Diesel engine on/off
18.
Fuel tap wi
th filter
19. Earthing
screw
General Safety Instructions
Prior to the in
itial use of the unit, the operating instructions should be read completely. If in doubt with
regard to connection and operation of the unit, consult the manufacturer (servicing department).
FOLLOW THE INSTRUCTIONS BELOW CAREFULLY IN ORDER TO SECURE A HIGH DEGREE OF
SAFETY:
CAUTION!
x Invite a professional electrician when connecting the generator to a house supp
ly
sou
rce to check the connection and grounding
.
x
Always place the generator on firm flat base!
x Never use the generator in closed spaces. The flue gases may be
fatal.
x Never cover up the generator.
x Never touch it with wet hands.
x Do not work in moist conditions.
x Never connect 2 generators together.
Use of the electric tools requires ob
servance of the attached safety instructions and accessory
safety instructions.
A risk of injury or damage of the electrical tool. The appliance technical data should
match the safety instructions on the generator. (With start up output, 3-5 multiple of
the connected unit nominal output should be observed).
1
2 2
3
4
5
6 8
7
9
10
11
14
12
13
15
16
17
19
18
