Installing Transmitter Battery
Note: Battery is included, but not installed to help prevent loss of battery strength when
new.
(1) Remove any static charges from your body by touching a metal grounded object.
(2) Remove Transmitter from console mounting bracket, by slightly bending the tab
back to release the transmitter from the bracket.
(3) Remove the two screws on the back of the transmitter with a Philips screwdriver.
With a coin, lightly pry open the transmitter case using the slot in the bottom corner
opposite of the key ring hole.
(4) Carefully separate the case halves. See illustration for disassembly below.
(5) Place the 12 Volt Alkaline A23 battery in location per Figure 1 below paying close
attention to the + / - orientation.
Slot
Tab (2)
