9
Re-insert the flange
(
7
)
, press the flange
(
7
)
to keep the blade or other accessory
temporarily secure. Flip the tool- free blade change lever
(
1
)
back to original position to
secure the accessory. (SEE FIG. C1 C2)
ASSEMBLING / CHANGING THE SANDING SHEET (SEE FIG. D, E)
(1) please follow the same steps for assembling / changing as above instruction.
(2) Place the mesh sanding sheet directly onto the base plate and press the sheet onto the pad.
Firmly press the oscillating tool with the installed sanding sheet against a flat surface and
briefly switch the power tool on. This provides for good adhesion and prevents premature wear.
If one point has become worn after use, pull off the sanding sheet, turn it 120°, and re-install.
2. OPERATING THE ON/OFF SWITCH (SEE FIG. F)
——Switching the power tool ON:
Slide switch forward.
——Switching the power tool OFF:
Slide switch backward.
Operating Instructions
C1 C2
D E
Operation instructions
