Guildline Autosal 8400B - Figure 7.1: Connector Pinouts

Section 7
TM8400B-L-00
1 November 2004
7-2
PIN NUMBER
BCD CODING
FUNCTION
BINARY BIT
EXAMPLE
3 2 1 0
READING
LOGIC
Bottle No. Digit 4 (LSD)
13 12 11 10
0
0 0 0 0
Digit 3 (3rd MSD)
17 16 15 14
9
1 0 0 1
Digit 2 (2nd MSD)
46 45 44 43
8
1 0 0 0
Digit 1 (MSD)
50 49 48 47
7
0 1 1 1
Display Digit 6 (LSD)
37 36 34 35
6
0 1 1 0
Digit 5 (5th MSD)
41 38 39 40
5
0 1 0 1
Digit 4 (4th MSD)
24 25 26 27
4
0 1 0 0
Digit 3 (3rd MSD)
18 19 22 20
3
0 0 1 1
Sign
- - - 23
+
- - - 0
Display Digit 2 (2nd MSD)
4 3 5 6
2
0 0 1 0
Decimal
- - - 8
.
- - - 0
Display Digit 1 (MSD)
- - 2 1
1
- - 0 1
Table 7-1: BCD Connector Pin Coding
Figure 7.1: Connector Pinouts
