EN
47
8. MACHINING - WORKTOP - BASE CABINET
1. Remove the front or drawers.
2. Define and mark the positions for the cut-out on the kitchen worktop. Please pay
attention to minimum distances and minimum web width! These may vary depending
on the material and material properties!
(Under certain circumstances use auxiliary crossbar "Reinforcement").
3. Saw out the cut-out on the worktop.
Pay attention to straightness and freedom
from burrs ! For "flush installation", mill
out the recess.
4. Seal milled surfaces.
5. If necessary, make cut-outs in the base cabinet floor and plinth.
Adjust rear drawer panels if necessary.
