11. Reverse the middle hinge 180°C, then transfer
it to the left position. Insert the middle hinge pin
in the upper hole of the lower door, then tighten
the bolts.
Ensure the door is aligned horizontally and
vertically so that the seals are closed on all
sides before finally tightening the hinge.
12. Place the upper door back on. Ensure the
door is aligned horizontally and vertically so
that the seals are closed on all sides before
finally tightening the top hinge.
13. Insert the hinge bracket and screw it to the
top of the unit.
14. Use a spanner to tighten it if necessary.
15. Put the hinge cover and the screw cover back.
16. With the doors closed, check that the doors
are aligned horizontally and vertically and that
the seal is closed on all sides before finally
tightening the bottom hinge. Re-adjust the
levelling feet as needed.
