GW Instek ASR-2000 Series Quick Start Guide

6
Appearance
Front Panel Overview
1
10
9
8
7
6
5432 11
12
13
14
1521 20 19 18 17 16
22
Description
1. Power switch button
2. Lock/Unlock button
3. Hardcopy key
4. USB interface connector (A Type)
5. Menu key/On phase key
6. Preset key/Local mode key
7. Shift key
8. Cancel key/ALM CLR key
9. Test key/Output waveform key
10. Output key
11. Enter key
12. Arrow keys
13. Scroll wheel
14. Function keys (blue zone)
15. Display mode select key
16. Range key/Output mode key
17. Irms/IPK-Limit button
18. F/F-Limit button
19. V/V-Limit button
20. LCD screen
21. Air inlet
22. Output socket

GW Instek ASR-2000 Series Specifications

General

Brand	GW Instek
Model	ASR-2000 Series
Category	Portable Generator
Language	English
